Laser and Spectroscopy

The MRL Laser and Spectroscopy Core is a user-oriented, user-friendly facility that provides the modern photon-based analytical capabilities essential to today’s materials science. These services emphasize the study of optical properties of materials and interfaces, and the relation to microstructural and microchemical composition, phase transitions, crystalline, electronic, and defect structure of materials, surfaces, and interfaces.

Many of the instruments of the Laser and Spectroscopy Core require the use of lasers, therefore requiring laser safety training. See below for more details on the offered trainings.

Laser Safety

Many of the instruments of the Laser and Spectroscopy Core require the use of lasers and require laser safety training. There are two levels of safety training: online and hands-on. The online training is offered by the Division of Research Safety (DRS) and need to be renewed annually. After completing this training, you must upload its certificate of completion through Canvas (https:go.illinois.edu/MRLLaserSafety).

The instruments that involve direct alignment and manipulation of laser beam paths require a hands-on training, in addition to the DRS training. This training can be requested through the Instrument Scheduling tool, in the same way you would request training on an instrument, and it is called Hands-on Laser Safety Training.

Techniques

Microscopy

The microscopy suite in the Laser and Spectroscopy Core encompasses a wide variety of instruments for imaging and mapping of material properties. Available modalities include confocal 3D optical profilometry, confocal Raman and fluorescence microscopy, scattering scanning near-field FTIR spectroscopy, C-DIC, TIC, polarization, phase, brightfield, and darkfield. Available geometries are inverted and upright using reflected or transmitted illumination.

Spectroscopy

Spectroscopy uses the interaction of electromagnetic radiation with matter to characterize optical, thermal, mechanical and electronic properties of materials. The MRL facilities include conventional, state-of-the-art spectroscopic tools in addition to techniques and instrumentation developed in house.

Ellipsometry

Ellipsometry is an optical method used for the characterization of surfaces and thin film layers by measuring the change in polarization of light reflected or transmitted from them. Commonly used to determine layer thickness and optical constants, in some cases ellipsometry can also be applied to determine composition, crystallinity, roughness, and other material properties associated with changes in optical response.

Light Sources

We have a varied assortment of lamps and pulsed and continuous-wave lasers, including an ultrafast UV to IR Optical Parametric Oscillator, a supercontinuum 480 nm to 2400 nm pulsed laser, and several ultrafast (<0.5 ps pulse width) laser sources.

Cryostats

MRL's cryostats enable low-temperature spectroscopy down to 1.5K.

Contact Angle Goniometry

This technique is used to quantify the wettability of a solid surface by a liquid, as well as determining surface free energy, surface tension, and interfacial tension between materials.

Scanning Probe Optical Spectroscopy

Atomic force microscopy and optical characterization combine to give surface chemical information.

Equipment in this Core
