MJB4 Mask Aligner

Equipment Location:
313 MRL

Easy to use the Karl Suss MJB-4 is the perfect system for research and small laboratories.

 The MJB-4 offers flexibility in the handling of irregularly shaped substrates and pieces of differing thicknesses, as well as standard size wafers up to 3 inches in diameter. Equipped with a reliable, high precision alignment and high resolution printing capability in the sub-micron range, the MJB-4 offers a performance unsurpassed by any comparable aligner

Capabilities:

High resolution printing down to .05 microns

Fast and accurate alignment with Suss Singlefield or Splitfield Microscope

High Resolution Optics optimized for thick resists
